Produktfunksjoner:
- Sentrale og perifere K-verdier
- Automatisk justering og automatisk måling
- Pupil – og hornhinne-ø-måling
- IOC/CAT modus for katarakt måling og pseudofakiske øyne
Refractive power measurement:
SPHERICAL REFRACTIVE POWER (S)
Measurement range
-25.00 D to +22.00 D (at VD=12.0 mm)
Cylindrical (CYL)
0 D to ±10.00 D (at VD=12.0 mm)
Display unit
0.01 D, 0.12 D, 0.25 D
CYLINDRICAL REFRACTIVE POWER (C)
Measurement range
0 D to ±10.00 D (at VD=12.0 mm)
Display unit
0.01 D, 0.12 D, 0.25 D
ASTIGMATISM AXIAL (A)
Measurement range
0° to 180°
Display unit
1°
CORNEAL CURVATURE MEASUREMENT (K1, K2, AVG)
Measurement range
5.00 mm to 11.00 mm / 30.68 D to 67.50 D (n=1.3375)
Display unit
0.01 mm
CORNEAL ASTIGMATISM AND AXIS (C, A)
Measurement range (C)
0 D to 10 D (n=1.3375)
Measurement range (A)
0° to 180°
Measurement area cornea
Ø 3.0 mm / Ø 6.0 mm (at 8.00 mm corneal curvature)
PD range
50 to 86 mm
Minimum pupil diameter
Ø 2.2 mm
Vertex distance
0 mm – 16.0 mm
MAIN UNIT
Built-in printer
Thermal printer
Output
RS-232C
Display
5.7“ colour LCD
Chin rest
electr. controlled
DIMENSIONS AND ELECTRIC REQUIREMENTS
Dimensions (WxDxH)
300 × 493 × 466 mm
Weight
approx. 19 kg
Input
100 to 240 V AC
Frequency
50/60 Hz
Power consumption
130 VA to 150 VA
